0 to +160°C Stainless Steel Bimetallic Industrial Thermometer 63mm Cabinet 100mm Stem Rear

0 to +160°C Stainless Steel Bimetallic Industrial Thermometer 63mm Cabinet 100mm Stem Rear
Image may vary slightly
See specifications for accurate information.
Reference: TBLRSH-160-63-100-G-43
Brand: WIKA

Rear connection bimetallic industrial thermometer with a stainless steel cabinet for measuring temperatures from 0 to +160°C. Mount the thermometer with a female G 1/2 inch thread or combine it with a thermowell and then mount. The stainless steel design enables operation up to a maximum pressure of 25 bar (363 psi). The thermometer has a 63 mm cabinet and a 100 mm long, 8 mm wide stainless steel stem that contains the bimetallic coil. Manufactured to a tolerance class 1, according to EN 13190. It has a wide range of applications in machine building, air-conditioning, piping and apparatus construction. IP43 degree of protection.

View all
Regular price
£57.03
excl VAT

In stock +2 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 2 days. Up to 3 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.


Shipping to United Kingdom: £6.95
Free for orders > £75.00
Expected delivery in 4 - 6 business days

Description
Specifications
Downloads
Related products

This rear connection industrial bimetallic thermometer has a wide range of applications in machine building, air-conditioning, piping and apparatus construction. It can measure temperatures from 0 to +160°C and withstand environment temperature ranging from -20 to +60°C. The thermometer has a 63 mm wide cabinet and a 100 mm long, 8 mm wide stainless steel stem that contains a bimetallic coil. Mount the thermometer with a female G 1/2 inch thread or combine it with a thermowell and then mount. The stainless steel design enables operation up to a maximum pressure of 25 bar (363 psi). The thermometer is manufactured to a tolerance class 1, according to EN 13190. It has an IP43 degree of protection.

Pros:

  • Accuracy class 1 in accordance with EN 13190
  • Simple and low maintenance design
  • Not prone to malfuntion due to the mechanical design
  • Suitable for a maximum pressure of up to 25 bar (362 psi)
  • IP43 degree of protection.

Cons:

  • Not equipped with a thermowell

A52 series

The A52 series of bimetallic industrial thermometers is designed for temperature indication in machine building, air-conditioning, piping and apparatus construction. Scale ranges from -30 to 500°C and these thermometers can be used in ambient temperatures ranging from -20 to 60°C. Display width ranges from 63 to 200 mm while stem length ranges from 63 to 200 mm. They have stainless steel housing and stems. The stainless steel design makes them suitable for a maximum operating pressure of up to 25 bar. These thermometers are manufactured to a tolerance class 1 in accordance with EN 13190.
