Dehn Aluminum Gutter Clamp With Clamping Frame 16-22mm - 339101

Dehn Aluminum Gutter Clamp With Clamping Frame 16-22mm - 339101
Dehn Aluminum Gutter Clamp With Clamping Frame 16-22mm - 339101
Dehn Aluminum Gutter Clamp With Clamping Frame 16-22mm - 339101
Dehn Aluminum Gutter Clamp With Clamping Frame 16-22mm - 339101
Image may vary slightly
See specifications for accurate information.
Reference: E3P5R
Brand: DEHN
Mfr. Part: 339101

The Dehn gutter clamp for lightning protection is designed to connect round conductors with the gutter bead as per EN 62561-1 standard. It employs a single-screw technique with a clamping piece, facilitating longitudinal conductor routing for efficient and secure installation. It serves as a practical and reliable solution for routing conductors in lightning protection systems.

View all
Note: product cannot be returned
£4.61
excl VAT
In stock +11 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 11 days. Up to 100 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United Kingdom: £6.95
Free for orders > £75.00
Expected delivery in 13 - 15 business days

Customers rate us: 4.90 / 5

383 reviews at TrustedShops

Description
Specifications
Downloads

Description

The Dehn gutter clamp for lightning protection is designed to connect round conductors with the gutter bead as per EN 62561-1 standard. It employs a single-screw technique with a clamping piece, facilitating longitudinal conductor routing for efficient and secure installation. It serves as a practical and reliable solution for routing conductors in lightning protection systems.

Downloads

Product datasheet (EN)
pdf
Download

Specifications

Type of connector
Gutter clamp
Suitable for diameter round conductor (mm)
8 mm to 10 mm
Clamping range (mm)
Suitable for hoses with an outside diameter that falls between the two values.
16 mm to 22 mm
Material
Choose a housing material that is not corroded by the media and environment, and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Aluminium
Surface protection
The type of surface protection of the component.
Untreated
Type of fastening screws
Hexagon screw
