Distributor G1/4 3300 l/min Narrow with Pressure Switch Multifix 1
This is a narrow compressed air distributor with pressure switch. It has 1 inlet and 4 outlet connections of G 1/4 inch. It can be used as an intermediate distributor for varying compressed air qualities. The maximum flow rate is 3300 l/min. The pressure switch installed at connection B. Pressure switch has settings range: 0.2 - 16 bar, voltage DC: 12 - 30 V, max. 3 A/90 W, voltage AC: 12 - 250 V, max. 5 A/750 VA, degree of protection: IP 65 and plug DIN-A (4-pin).
- Regular price
- £125.18
Description
This is a narrow compressed air distributor with pressure switch. It has 1 inlet and 4 outlet connections of G 1/4 inch. It can be used as an intermediate distributor for varying compressed air qualities. The maximum flow rate is 3300 l/min. The pressure switch installed at connection B. Pressure switch has settings range: 0.2 - 16 bar, voltage DC: 12 - 30 V, max. 3 A/90 W, voltage AC: 12 - 250 V, max. 5 A/750 VA, degree of protection: IP 65 and plug DIN-A (4-pin).
