Eaton 4P Terminal Plate 120-300mm2 560A BBA-TP4/300 - 138385
The Eaton Industries XEffect connection kit is designed for a 60mm system with 4 poles. It features a terminal capacity of 95-300mm² MCM 300-MCM 600. The kit is silicon free and chlorine free with self-extinguishing properties to UL 94. It has a track resistance of CTI 200 and is temperature resistant to 120 °C. The pole pitch is adjustable, and the kit can be fixed directly over busbar terminals. The kit includes a shroud with an adjustable width of 180 - 228mm. It is suitable for rails of dimensions 20x5/10, 25x5/10, 30x5/10 and double T profile. However, passing through is not possible. The maximum nominal operating current is 560A.
- Regular price
- £180.21
Description
The Eaton Industries XEffect connection kit is designed for a 60mm system with 4 poles. It features a terminal capacity of 95-300mm² MCM 300-MCM 600. The kit is silicon free and chlorine free with self-extinguishing properties to UL 94. It has a track resistance of CTI 200 and is temperature resistant to 120 °C. The pole pitch is adjustable, and the kit can be fixed directly over busbar terminals. The kit includes a shroud with an adjustable width of 180 - 228mm. It is suitable for rails of dimensions 20x5/10, 25x5/10, 30x5/10 and double T profile. However, passing through is not possible. The maximum nominal operating current is 560A.
