Eaton Installation Contactor 230VAC 50Hz 40A 2NO Z-SCH230/40-20 - 248855
The Eaton Industries Z SCH is a modular installation contactor with a rated control circuit voltage of 230V AC and a rated operational current at AC1 of 40A. Its operational voltage (measurement voltage) is 440V, and its energizing voltage ranges from 195.5 to 253V. The voltage type for both the operating voltage and the energizing is AC. The unit features 2 make contacts and a maximum incandescent lamp load of 5520W. Designed to comply with IEC 61095, EN 61095, VDE 0660, IEC 60947-4-1_x, EN 60947-4-1, VDE standards, its front dimension is a standard 45mm and its mounting width is 3 SU (52.5mm), suitable for top-hat rail mounting.
- Regular price
- £71.37
Description
The Eaton Industries Z SCH is a modular installation contactor with a rated control circuit voltage of 230V AC and a rated operational current at AC1 of 40A. Its operational voltage (measurement voltage) is 440V, and its energizing voltage ranges from 195.5 to 253V. The voltage type for both the operating voltage and the energizing is AC. The unit features 2 make contacts and a maximum incandescent lamp load of 5520W. Designed to comply with IEC 61095, EN 61095, VDE 0660, IEC 60947-4-1_x, EN 60947-4-1, VDE standards, its front dimension is a standard 45mm and its mounting width is 3 SU (52.5mm), suitable for top-hat rail mounting.
