Eaton Installation Contactor 230VAC 50Hz 4NC 25A 2HP - 248848
The Eaton Industries Installation Contactor is a modular unit with a rated operational current of 25A and a control circuit voltage of 230V AC. It features a maximum incandescent lamp load of 3000W and a company voltage (measuring voltage) of 440V. The unit operates with an energizing voltage range of 195.5 - 253V. It has an AC voltage type for both the operation and energizing voltages. The installation contactor comes with four break contacts and complies with IEC 61095, EN 61095, VDE 0660, IEC 60947-4-1_x, EN 60947-4-1, and VDE standards. It has a standard front dimension of 45mm and a mounting width of 2 SU (35mm). It is suitable for top-hat rail mounting.
- Regular price
- £55.83
Description
The Eaton Industries Installation Contactor is a modular unit with a rated operational current of 25A and a control circuit voltage of 230V AC. It features a maximum incandescent lamp load of 3000W and a company voltage (measuring voltage) of 440V. The unit operates with an energizing voltage range of 195.5 - 253V. It has an AC voltage type for both the operation and energizing voltages. The installation contactor comes with four break contacts and complies with IEC 61095, EN 61095, VDE 0660, IEC 60947-4-1_x, EN 60947-4-1, and VDE standards. It has a standard front dimension of 45mm and a mounting width of 2 SU (35mm). It is suitable for top-hat rail mounting.
