Eaton Power Disconnect Relay Z-LAR32-S 250VAC 15-32A 1HP - 248261
The Eaton Industries Xpole power shutoff relay is a load shedding (current) relay with a rated current range of 15-32A. It has an integrated auxiliary contact: 1 N/O and operates at a rated voltage of 250V. It boasts a rated insulation voltage of 440V and can withstand impulse voltages up to 4 kV. Its compact design comes with a standard front dimension of 45mm and a mounting width of 1 SU (17.5mm). The relay is designed for top-hat rail mounting, and it features terminal cross-sections of the main circuit 2x10 mm², and the auxiliary circuit 2x2.5 mm².
- Regular price
- £50.27
Description
The Eaton Industries Xpole power shutoff relay is a load shedding (current) relay with a rated current range of 15-32A. It has an integrated auxiliary contact: 1 N/O and operates at a rated voltage of 250V. It boasts a rated insulation voltage of 440V and can withstand impulse voltages up to 4 kV. Its compact design comes with a standard front dimension of 45mm and a mounting width of 1 SU (17.5mm). The relay is designed for top-hat rail mounting, and it features terminal cross-sections of the main circuit 2x10 mm², and the auxiliary circuit 2x2.5 mm².
