Eaton Power Release Relay Z-LAR16-S 250V 10-16A 1HP - 248260
Notice: This product is discontinued
The Eaton Industries Xpole is a load shedding relay with a rated current range of 10-16A. This relay features an integrated auxiliary contact, 1 N/O, and operates at a rated voltage of 250V. Its insulation voltage is rated at 440V and it can withstand an impulse of up to 4 kV. It possesses a standard front dimension of 45mm and a mounting width of 1 SU (17.5mm). The relay is suitable for top-hat rail mounting. The terminal cross-section of the main circuit is 2x10 mm² while the auxiliary circuit's terminal cross-section is 2x2.5 mm².
Notice: This product is discontinued
Description
The Eaton Industries Xpole is a load shedding relay with a rated current range of 10-16A. This relay features an integrated auxiliary contact, 1 N/O, and operates at a rated voltage of 250V. Its insulation voltage is rated at 440V and it can withstand an impulse of up to 4 kV. It possesses a standard front dimension of 45mm and a mounting width of 1 SU (17.5mm). The relay is suitable for top-hat rail mounting. The terminal cross-section of the main circuit is 2x10 mm² while the auxiliary circuit's terminal cross-section is 2x2.5 mm².
