Eaton Release Relay Z-LAR8-S 250VAC 1N/O 3-8A 1HP - 248259

Eaton Release Relay Z-LAR8-S 250VAC 1N/O 3-8A 1HP - 248259
Eaton Release Relay Z-LAR8-S 250VAC 1N/O 3-8A 1HP - 248259
Image may vary slightly
See specifications for accurate information.
Reference: E3DT4
Brand: EATON INDUSTRIES
Mfr. Part: 248259

The Eaton Industries Xpole is a load shedding relay with a rated current range of 3-8A. It features an integrated auxiliary contact: 1 N/O, a rated operating voltage of 250V, a rated insulation voltage of 440V, and a rated impulse withstand voltage of 4 kV. With a standard front dimension of 45 mm and a mounting width of 1 SU (17.5mm), it is designed for top-hat rail mounting. It has a terminal cross-section for the main circuit of 2x10 mm² and a terminal cross-section for the auxiliary circuit of 2x2.5 mm².

View all
Note: product cannot be returned
£57.24
excl VAT
In stock Ships in 38d Not available Not available
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 38 days. Up to 46 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United Kingdom: £6.95
Free for orders > £75.00 (excl VAT)
Expected delivery in 40 - 41 business days

Customers rate us: 4.87 / 5

587 reviews at TrustedShops

Description
Specifications

Description

The Eaton Industries Xpole is a load shedding relay with a rated current range of 3-8A. It features an integrated auxiliary contact: 1 N/O, a rated operating voltage of 250V, a rated insulation voltage of 440V, and a rated impulse withstand voltage of 4 kV. With a standard front dimension of 45 mm and a mounting width of 1 SU (17.5mm), it is designed for top-hat rail mounting. It has a terminal cross-section for the main circuit of 2x10 mm² and a terminal cross-section for the auxiliary circuit of 2x2.5 mm².

Specifications
