Eaton Signal Lamp LED 12-24VAC/DC Single Light Green Z-BEL/G24 - 284932
Notice: This product is discontinued
The Eaton Industries Z BEL is a modular acoustics signal device with an optional green optical signal. The nominal measuring voltage is 24V, with a maximum power loss of 2W. It has a switching frequency of 2kHz, and can operate on both AC and DC voltage types. Its installation depth is 60mm and it has an IP40 protection degree. The signal device is of the optical type and is mounted onto a DIN-rail. The device dimensions cater to a single module. The lamp, coming with an integrated flashing function, has a rated operating voltage of 24V AC/DC. The LED is green in color and its brightness is 15mcd. Heat dissipation stands at 2W/LED, with a standard norm flashing frequency of 2 Hz. The lamp has a standard 45 mm front dimension with a 1 SU mounting width (17.5mm). The lamp is also top-hat rail-mountable, with a terminal cross-section of 1-10mm², and is compliant with IEC/EN 60669, VDE 0632 type standards.
Notice: This product is discontinued
Description
The Eaton Industries Z BEL is a modular acoustics signal device with an optional green optical signal. The nominal measuring voltage is 24V, with a maximum power loss of 2W. It has a switching frequency of 2kHz, and can operate on both AC and DC voltage types. Its installation depth is 60mm and it has an IP40 protection degree. The signal device is of the optical type and is mounted onto a DIN-rail. The device dimensions cater to a single module. The lamp, coming with an integrated flashing function, has a rated operating voltage of 24V AC/DC. The LED is green in color and its brightness is 15mcd. Heat dissipation stands at 2W/LED, with a standard norm flashing frequency of 2 Hz. The lamp has a standard 45 mm front dimension with a 1 SU mounting width (17.5mm). The lamp is also top-hat rail-mountable, with a terminal cross-section of 1-10mm², and is compliant with IEC/EN 60669, VDE 0632 type standards.
