ESYLUX Compact Motion Switch (Complete) - EP10425288
This motion detector from the COMPACT series from ESYLUX is a presence sensor that responds to light and heat sources, with a 360° detection angle, a range of approximately 11/24 meters (frontal/cross). Perfect for classrooms, offices, meeting rooms and transit areas with natural light. The motion detector is only suitable for ceiling mounting (optimally at a height of 3 meters, maximum 10 meters). The higher you hang the motion detector, the greater the range, only the sensitivity also decreases.
- Regular price
- £147.25
Description
The text describes a presence detector with a 360° field of detection designed for ceiling mounting. It has a detection range of up to 24 m in diameter at a recommended installation height of 3 m. This makes it suitable for use in offices, classrooms, board rooms, and passageways with natural lighting. It is also ideal for areas with ceilings of up to 10 m, such as sports halls and warehouses.
The device comes with a 16 A high-performance relay (tungsten pre-contact), making it perfect for switching capacitive loads, like:
- Electronic ballasts,
- Parallel-compensated fluorescent lamps,
- Compact fluorescent lamps,
- Energy saving lamps.
It is immediately operable due to its default settings.
The detector controls light automatically (channel 1) based on presence and natural light. It also has an additional floating HVAC switch contact (channel 2) for controlling heating, ventilation, and air conditioning according to presence. Programming is made simple with the use of remote control featuring blue mode technology or setting elements like a potentiometer.
The device also has an integrated toggle for setting with remote control or by adjusting the controller, which helps prevent operating errors and provides tamper protection. It is possible to mask interference sources by reducing sensitivity using DIP switches. There is an additional switch input with a toggle function.
The detector is versatile and can be used as a fully automatic or semi-automatic device (channel 1). It comes as a flush-mounted device, with the ability for surface mounting or recessed ceiling mounting with accessories. The cover and design ring are easily replaceable and paintable and available in silver. The field of detection can be extended by connecting slave devices, and areas can be targeted for masking out by using an enclosed lens mask.
