Belimo Flow Sensor DN15 G3/4'' 0.5l/s 24VAC/DC 22PF-1UC

This Belimo flow sensor is a highly efficient device that measures flow values. This sensor has a port size of G 3/4 inch. The flow sensor can measure a maximum flow at full scale of 0.5 l/s. The power supply voltage is 24 V AC/DC. The output signal is 0-10 V/2-10 V. The flow sensor has a protection rating of IP54. The sensor communicates via BACnet MS/TP, Modbus RTU, and MP-Bus. It has a pressure capacity of 25 bar and a theoretical kvs value of 3.9 m3/hr. This sensor is specifically designed for closed cold and hot water systems containing water or water-glycol mixtures. The flow sensor measures the glycol content of the medium continuously and compensates for it to ensure accurate measurement. This flow sensor allows for the accumulation of the flow rate. Programming is carried out with the Belimo Assistant App via NFC technology.

Pros:

• Accurate and precise flow measurement with ±2% accuracy of reading and ±0.5% reproducibility
• Ultra-compact size with a short 5 x DN inlet section and no outlet length requirements allows installation in confined spaces
• Energy-efficient with low consumption of only 0.5 W
