Image may vary slightly
See specifications for accurate information.
Reference: P264N
Brand: Knocks
Mfr. Part: DO.86

This G 1 1/4 inch pneumatic lubricator introduces a fine mist of oil into the air to reduce internal friction in components. Suitable for a 16.0 bar (232 psi) max input and temperatures between -10 and 60 °C (14 and 140 °F). The min flow for oil drip is 85 l/min. The oil capacity is 1700 cm3.

View all
£305.89
excl VAT
In stock +0 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 0 days. Up to 1000 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United Kingdom: Free
Free for orders > £75.00
Expected delivery in 2 - 4 business days

Customers rate us: 4.90 / 5

383 reviews at TrustedShops

Description
Specifications
Downloads

Description

The lubricator introduces a fine mist of oil into the pneumatic air to reduce internal friction of pneumatic parts. Most modern pneumatic equipment doesn't need lubrication, only use a lubricator if downstream equipment requires it. The recommended lubricating oil type is ISO-VG32 turbine oil. This model has G 1 1/4 inch ports.

The maximum input pressure is 16.0 bar (232 psi) and the temperature range is between -10 and 60 °C (14 and 140 °F). The lubricator requires a minimal flow rate of 85 l/min and can hold 1700 cm3 of oil. The housing material is made out of zinc die-cast and the lubricator has a bowl made of polycarbonate (PC). The bowl has protective cage.

Mounting brackets need to be ordered separately.

Downloads

Manual Standard
pdf
Download
Knocks Standard
pdf
Download

Specifications

Connection size
Choose a connection size that matches the system it will be connected to. Tip: the inch size is not equal to the actual diameter of the thread, when in doubt use our thread table.
1 1/4 inch
Max flow rate (l/min)
11000
Max. pressure difference at 20 °C (bar)
Maximum pressure difference between output and input at room temperature.
16
Min pressure (bar)
0
Connection type
Inner thread cylindrical BSPP-G
Min. flow for oil drip (l/min)
85
Lubricating oil capacity (cm³)
1700
FRL feature
Protective cage
Material
Choose a housing material that is not corroded by the media and environment, and can withstand the temperatures and pressures. Check out our chemical resistance chart.
Zinc die-cast
With mounting bracket
No
Model
Standard 8
Min temperature (°C)
The minimum temperature of the fluid at which the system can operate continuously.
-10
Max temperature (°C)
The maximum temperature of the fluid at which the system can operate continuously.
60
Height (mm)
The product's height without packaging.
448
Length (mm)
The product's length without packaging.
150
Container material
Polycarbonate (PC)
