Reference: MVSC1-180-3B2-G
Brand: Mindman

Strong and lightweight manifold for up to 2- pneumatic solenoid valves from the Mindman MVSC1-180 3-way series. Includes rubber seals and bolts to mount the valves. Unused stations can be closed by blocking plates (separately available). The in- and outlet ports have G1/4&quot threads on both sides of the manifold. This manifold is an efficient way to reduce tubing, fittings and fixtures, but also to simplify installation and maintenance.
