Nitrogen Pressure Regulator 200 bar to 0-10 bar W24.3x1/14 Female
This brass cylinder pressure regulator is suitable for nitrogen at a maximum pressure of 200 bar. It lowers the inlet pressure to an adjustable range of 0-10 bar. The W 24.3 x 1/14 female threaded port connects to the supply bottle (conforming DIN 477-5). The G 1/4 inch male threaded port connects to a suitable hose. To set the pressure, screw the rod, on the lower side of the body, in or out using a handle. The pressure gauge on the inlet port indicates the inlet pressure and the pressure gauge on the outlet port indicates the preset or working pressure. This regulator is designed for safety in accordance with DIN EN ISO 2503.
- Regular price
- £117.12
Description
This brass cylinder pressure regulator is suitable for nitrogen at a maximum pressure of 200 bar. It lowers the inlet pressure to an adjustable range of 0-10 bar. The W 24.3 x 1/14 female threaded port connects to the supply bottle (conforming DIN 477-5). The G 1/4 inch male threaded port connects to a suitable hose. To set the pressure, screw the rod, on the lower side of the body, in or out using a handle. The pressure gauge on the inlet port indicates the inlet pressure and the pressure gauge on the outlet port indicates the preset or working pressure. This regulator is designed for safety in accordance with DIN EN ISO 2503.
Pros:
- Regulates nitrogen up to 200 bar to a 0-10 bar pressure
- Inlet and outlet pressure gauge with rugged rubber cover
- Safe design meeting DIN EN ISO 2503
- W 24.3 x 1/14 female threaded bottle connection conforms to DIN 477-5 standard (not CGA)
