Operating distance (mm)
5 mm to 2500 mm
Max. switching distance (mm)
2500
Max. output current (mA)
3000
Rated control supply voltage Us at AC 50HZ (V)
24 V to 240 V
Rated control supply voltage Us at AC 60HZ (V)
24 V to 240 V
Rated control supply voltage Us at DC (V)
24 V to 240 V
Analogue output 0 V ... 10 V
No
Analogue output 0 mA ... 20 mA
No
Analogue output 4 mA ... 20 mA
No
Analogue output -10 V ... +10 V
No
With other analogue output
No
Setting procedure
Manual adjustment
With communication interface analogue
No
With communication interface AS-Interface
No
With communication interface CANOpen
No
With communication interface DeviceNet
No
With communication interface Ethernet
No
With communication interface INTERBUS
No
With communication interface PROFIBUS
No
With communication interface RS-232
No
With communication interface RS-422
No
With communication interface RS-485
No
With communication interface SSD
No
With communication interface SSI
No
Degree of protection (IP)
IP64
Type of switch function
Programmable/configurable
Operation agent-safety class
Safety class 2
Sensing mode
Light-/dark switching
Material of optical surface
Plastic
Min. reflector distance (mm)
0
Transmission range of the safety field (m)
6
Switching frequency (Hz)
50
Type of safety according to IEC 61496-1
1
Switching voltage of OSSD at state "high" (V)
0
Laser protection class
None
Wavelength of the sensor (nm)
624
Type of light
Polarity free red light
Material of cable sheath
Polyvinyl chloride (PVC)
Suitable for safety functions
No
Degree of protection (NEMA)
Other
Ambient temperature (°C)
-25 °C to 55 °C
