+20 to +100°C Petrochemical Stainless Steel Bimetallic Thermometer 100mm Cabinet 100mm Stem Bottom

+20 to +100°C Petrochemical Stainless Steel Bimetallic Thermometer 100mm Cabinet 100mm Stem Bottom
Image may vary slightly
See specifications for accurate information.
Reference: TBLUSH-120-100-100-G-65
Brand: WIKA

Bottom connection fully stainless steel bimetallic thermometer for measuring temperatures from +20 to +100°C. Mount the thermometer with a female G 1/2 inch thread or combine it with a thermowell and then mount. The stainless steel design enables operation up to a maximum pressure of 25 bar (363 psi). The thermometer has a 100 mm cabinet and a 100 mm long, 8 mm wide stainless steel stem that contains the bimetallic coil. Manufactured to a tolerance class 1, according to EN 13190. It is suitable for the chemical and petrochemical industries, oil and gas industries and other harsh and aggressive environments. IP65 degree of protection.

View all
Regular price
£184.39
excl VAT

In stock +2 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 2 days. Up to 5 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.


Shipping to United Kingdom: Free
Free for orders > £75.00
Expected delivery in 4 - 6 business days

Description
Specifications
Downloads
Related products

This bottom connection fully stainless steel bimetallic thermometer is suitable for the chemical and petrochemical industries, oil and gas industries and other harsh and aggressive environments. It can measure temperatures from +20 to +100°C and withstand environment temperature ranging from -40 to +70°C. The thermometer has a 100 mm wide cabinet and a 100 mm long, 8 mm wide stainless steel stem that contains a bimetallic coil. Mount the thermometer with a female G 1/2 inch thread or combine it with a thermowell and then mount. The stainless steel design enables operation up to a maximum pressure of 25 bar (363 psi). The thermometer is manufactured to a tolerance class 1, according to EN 13190. It has an IP65 degree of protection.

Pros:

  • Accuracy class 1 in accordance with EN 13190
  • Simple and low maintenance design
  • Not prone to malfuntion due to the mechanical design
  • Suitable for a maximum pressure of up to 25 bar (362 psi)
  • IP65 degree of protection.

Cons:

  • Not equipped with a thermowell

55 series

The 55 series of fully stainless steel bimetallic thermometers are designed for temperature indication in chemical and petrochemical industries, oil and gas industries and in various harsh and aggressive environments. Scale ranges from -70 to 600°C and these thermometers can be used in ambient temperatures ranging from -40 to 70°C. Display width ranges from 63 to 200 mm while stem length ranges from 63 to 200 mm. The stainless steel design makes them suitable for a maximum operating pressure of up to 25 bar (363 psi). These thermometers are manufactured to a tolerance class 1 in accordance with EN 13190.
