Power Team Threaded 5 Ton Hydraulic Jack 82.6 mm Stroke

Power Team Threaded 5 Ton Hydraulic Jack 82.6 mm Stroke
Power Team Threaded 5 Ton Hydraulic Jack 82.6 mm Stroke
Reference: H222U
Brand: Power Team

This is a Power Team single-acting, spring return, threaded 5 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 82.6 mm and a total height of 165.1 with retracted piston. It has a UNF 3/4“-16 female threaded piston rod and UN 11/2“-16 male threaded cylinder.

View all
£566.21
excl VAT
In stock +2 days On request On request
For a higher quantity than 0 of product H222U, the lead time of the order will increase by 2 days. The item is not online available in your chosen quantity, there are 4 items available for online order. For higher quantities please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United Kingdom: £6.95
Free for orders > £75.00
Expected delivery in 4 - 6 business days

Customers rate us: 4.8 / 5

435 reviews at Google

Description
Specifications
Downloads

Description

This is a Power Team single-acting, spring return, threaded 5 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 82.6 mm and a total height of 165.1 with retracted piston. It has a UNF 3/4“-16 female threaded piston rod and UN 11/2“-16 male threaded cylinder.

Pros:

  • Maximum operating pressure of up to 700 bar
  • Comes with an assembled coupling sleeve 9796
  • Robust and high-quality multi-purpose hydraulic jack
  • Equipped with a threaded piston rod and cylinder

Downloads

Specifications

Stroke (mm)
82.6
Overall height retracted (mm)
165.1
Internal diameter (mm)
If the diameter is too small, the pressure drop increases.
38
Force (t)
5
Thread size connection cylinder
UNF 3/4-16
Thread size connection piston rod
UN 11/2-16
Max pressure (bar)
700
