Power Team Threaded 55 Ton Hydraulic Jack 108.0 mm Stroke

Power Team Threaded 55 Ton Hydraulic Jack 108.0 mm Stroke
Power Team Threaded 55 Ton Hydraulic Jack 108.0 mm Stroke
Reference: H223U
Brand: Power Team

This is a Power Team single-acting, spring return, threaded 55 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 108 mm and a total height of 231.8 with retracted piston. It has a UN 5“-12 male threaded cylinder.

View all
£2037.97
excl VAT
In stock +2 days On request On request
For a higher quantity than 0 of product H223U, the lead time of the order will increase by 2 days. The item is not online available in your chosen quantity, there are 1 items available for online order. For higher quantities please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United Kingdom: £6.95
Free for orders > £75.00
Expected delivery in 4 - 6 business days

Customers rate us: 4.8 / 5

435 reviews at Google

Description
Specifications
Downloads

Description

This is a Power Team single-acting, spring return, threaded 55 ton hydraulic jack cylinder designed for lifting and crimping applications. The jack has a stroke length of 108 mm and a total height of 231.8 with retracted piston. It has a UN 5“-12 male threaded cylinder.

Pros:

  • Maximum operating pressure of up to 700 bar
  • Comes with an assembled coupling sleeve 9796
  • Robust and high-quality multi-purpose hydraulic jack

Downloads

Specifications

Stroke (mm)
108
Overall height retracted (mm)
231.8
Internal diameter (mm)
If the diameter is too small, the pressure drop increases.
127
Force (t)
55
Thread size connection piston rod
UN 5-12
Max pressure (bar)
700
