Schneider Electric M2 PLC Base Unit - TM241CE24R
Schneider electric logic controllers - modicon m241 range. The modicon m241 logic controller is for application for controlling of simple motion control machines and offers best-in-class communication with 5 embedded ports. It offers you state of the art technical features and embedded canopen for fieldbus architectures up to 63 devices while reducing your installation time and cost.
- Regular price
- £386.91
Description
This product is part of the Modicon M241 range, a selection of logic controllers for performance demanding applications. This logic controller provides 14 discrete, 8 fast inputs, 6 relay, 4 transistor, 4 fast outputs with a transistor, and an ethernet relay output. It has a rated supply voltage of 100V to 240V AC, an output voltage of 5V to 125V DC or 5V to 250V AC for relay, 24V DC for a transistor and an output current of 2A for relay, 0.1A for fast output, and 0.5A for a transistor.
The product enables one to build an application intuitively as never before due to an organized screen design. Integrated connections include a USB port with a mini B USB 2.0 connector, a non-isolated serial link 1 with an RJ45 connector and RS232/RS485 interface, and a non-isolated serial link 2 with a removable screw terminal block connector and an RS485 interface. This is a Modicon M241 controller with 8MB for the program, 64MB for system memory RAM, 128MB built-in flash memory for backup of user programs, and an SD card memory capacity of 16GB. It is an IP20 rated product.
Its dimensions are 150mm in width, 95mm in depth, and 90mm in height. It weighs 0.53kg. The Modicon M241 logic controllers are designed for high-performance compact machines incorporating speed and position control functions. The product is certified by CE, IACS E10, RCM, CSA, and CULus.
- It meets ANSI/ISA 12-12-01, CSA C22.2 No 142, CSA C22.2 No 213, EN/IEC 61131-22007, marine specification (LR, ABS, DNV, GL), UL 1604 and UL 508 standards.
- It supports DIN rail mount.
Achieve benchmark performance while increasing profitability with the Modicon M241 through intuitive machine programming with EcoStruxure Machine Expert, ready-to-use applications, and function blocks.
