Schneider Electric Round (Industrial) Connector - XZCC12FDM50B

Schneider Electric Round (Industrial) Connector - XZCC12FDM50B
Schneider Electric Round (Industrial) Connector - XZCC12FDM50B
Image may vary slightly
See specifications for accurate information.
Reference: E27VW
Brand: Schneider Electric
Mfr. Part: XZCC12FDM50B

Schneider Electric round (industrial) connector, contact design pin, connector diameter 12mm, thread size (metric) 12, 5 data contacts, for outer diameter cable 7mm, housing design straight, nom. (measuring) current In 3A, nom. (measuring) voltage 30V, connectable conductor cross-section fine 0 - 75mm².

View all
£7.65
excl VAT
In stock Ships in 3d On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 3 days. Up to 43 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United Kingdom: £6.95
Free for orders > £75.00
Expected delivery in 5 - 7 business days

Customers rate us: 4.80 / 5

406 reviews at TrustedShops

Description
Specifications

Description

Schneider Electric round (industrial) connector, contact design pin, connector diameter 12mm, thread size (metric) 12, 5 data contacts, for outer diameter cable 7mm, housing design straight, nom. (measuring) current In 3A, nom. (measuring) voltage 30V, connectable conductor cross-section fine 0 - 75mm².

Specifications

Contact type
Pin
Diameter connector
12 mm
Thread size M
12
Number of data contacts
5
For cable outer diameter
7..7 mm
Type of housing
Straight
Rated current In
3 A
Ambient temperature
-40..85 °C
Rated voltage
30 V
Connectable conductor cross section fine-strand without cable end sleeve
0..75 mm²
Connectable conductor cross section fine-strand with cable end sleeve
0..75 mm²
Connectable conductor cross section solid-core
0..75 mm²
Connectable conductor cross section multi-wired
0..75 mm²
Electrical connectioni
Screw connection
Material of contact surface
Other
Materiali
Other
Coating housing
None
Material thread ring
Other
Locking mechanism
None
Inflammability class of insulation material according to with UL94
Other
