WAGO 770-115 5-Pole Black Connector With Strain Relief - 770-115
Reference:
E3W4P
Brand:
Wago
Mfr. Part:
770-115
Professional 5-pole electrical connector featuring integrated strain relief housing. Rated for 400V AC/DC with 25A nominal current. Supports wire cross-sections from 0.5mm² to 4.0mm² (20-12 AWG). Constructed with UL 94 V-0 rated polyamide housing in black. Operating temperature range -5°C to +40°C with 10mm pitch spacing.
- Regular price
- £6.17
excl VAT
Shipping to United Kingdom: Free
Shipping to United Kingdom: £6.95
Free for orders > £75.00 (excl VAT)
Description
Specifications
Downloads
Related products
Description
Professional 5-pole electrical connector featuring integrated strain relief housing. Rated for 400V AC/DC with 25A nominal current. Supports wire cross-sections from 0.5mm² to 4.0mm² (20-12 AWG). Constructed with UL 94 V-0 rated polyamide housing in black. Operating temperature range -5°C to +40°C with 10mm pitch spacing.
Pros:
- Wide wire compatibility range (0.5-4.0mm²)
- High current rating of 25A
- Integrated strain relief for cable security
- UL 94 V-0 flame-retardant housing
