Comelit 316 DC Power Supply 33V | 1596B

Comelit 316 DC Power Supply 33V | 1596B
Comelit 316 DC Power Supply 33V | 1596B
Image may vary slightly
See specifications for accurate information.
Reference: E24EE
Brand: Comelit
Mfr. Part: 1596B

Comelit 316 Simplebus DC power supply unit, (wxdxh), 118x62x93mm. 1st Secondary voltage 29.7V - 36.3V. Voltage type supply voltage DC. Nominal supply voltage at AC 50Hz 88.8 - 264V. Maximum. Output current 1.82A, power output 60W. Modular design (for railmounting).

View all
Note: product cannot be returned
£200.80
excl VAT
In stock +15 days On request On request
0 are currently in your cart. For orders exceeding 0, expect an increased lead time of 15 days. Up to 12 items available for online order. For higher quantities, please contact us on support@tameson.com to request the lead time. The item is not available for online order, please contact us on support@tameson.com to request the lead time.
Shipping to United Kingdom: Free
Free for orders > £75.00
Expected delivery in 17 - 19 business days

Customers rate us: 4.90 / 5

383 reviews at TrustedShops

Description
Specifications
Downloads
Related products

Description

Comelit 316 Simplebus DC power supply unit, (wxdxh), 118x62x93mm. 1st Secondary voltage 29.7V - 36.3V. Voltage type supply voltage DC. Nominal supply voltage at AC 50Hz 88.8 - 264V. Maximum. Output current 1.82A, power output 60W. Modular design (for railmounting).

Downloads

Specifications

Voltage type of supply voltage
DC
1st secondary output voltage at DC (V)
29.7 V to 36.3 V
Max. output current 1 (A)
1.82
Secondary voltage adjustable
No
Nominal value output voltage 1 (V)
33
Nominal value output current 1 (A)
0.9
Rated voltage AC (V)
88 V to 264 V
Rated voltage DC (V)
31 V to 34 V
Electrical connection
Type of electric connection.
Screw-/spring clamp connection
Output voltage stabilized
No
Power consumption (VA)
72
Power output (W)
60
Stabilized
No
Short-circuit-proof
Yes
Degree of protection (IP)
The Ingress Protection (IP) rating indicating the product's resistance to dust and water, crucial for outdoor or harsh conditions.
IP20
Suitable for safety functions
No
SIL (IEC 61508)
None
Refurbished
No
Modular version
Yes
Direct mounting possible
Yes
Wall mounting possible
Yes
Rail mounting possible
Yes
Performance level (EN ISO 13849-1)
None
Degree of protection (NEMA)
EV001823
Width in number of modular spacings
7
Built-in width (mm)
108
Built-in height (mm)
93
