Steel DN 10 Hydraulic Coupling Socket 3/8 inch Male NPT Threads ISO 14540 D 19 mm
Steel DN 10 hydraulic coupling socket with 3/8 inch male NPT threads. The maximum operating pressure is 700 bar (10150 psi). The coupling is suitable for temperatures between -25 to 125 °C (-13 to 257 °F). The seal material is NBR. The coupling adheres the ISO 14540.
- Regular price
- £37.79
Description
Steel DN 10 hydraulic coupling socket with 3/8 inch male NPT threads. They are typically used for liquid lines to quickly connect and disconnect secure connections.
The 3/8 inch male NPT threads allow for it to be threaded onto a matching female threaded part. The maximum operating pressure is 700 bar (10150 psi). The coupling is suitable for temperatures between -25 to 125 °C (-13 to 257 °F). The seal material is NBR. The steel housing has a galvanic zink plated surface protection. The coupling complies with the ISO 14540 standard.
Pros:
- Sleeve and plug can be coupled and uncoupled under pressure
- Minor oil loss when uncoupling
- Compatible with Power Team couplings
- Adheres to ISO 14540
